还有0项未选择重置

选择代码

代码参数

公差等级

导入表面形状

材质

硬度

表面处理

选型参数

安装部直径D(mm) *

定位部直径P(mm) *

1.5~30/0.01

安装部长度L(mm) *

2~42/1

定位部长度B(mm) *

1.5~30/0.1

图片仅供参考

定位销大头球面型标准型

产品属性：

产品型号：请点击左侧选项进行选型重新选型

产品型号：待完成选型重置

含税总价：待选型

含税单价：待选型

未税单价：待选型

税率： 13.00%

购买数量	折扣	单价(未税)	单价(含税)	状态
暂无折扣

购买数量：

预计发货：0 天 按订单确认后起算

选型表

型号 / 代码	代码分类	型号 / D	D公差 / m6	D公差 / p6	最小单位0.01 / P	最小单位1 / L	最小单位0.1 / B	C	V	(W)
JT-RANSD	Dm6	1	+0.008 +0.002		1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANSU	Dm6	1	+0.008 +0.002		1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANSX	Dm6	1	+0.008 +0.002		1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANSL	Dm6	1	+0.008 +0.002		1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANDD	Dm6	1	+0.008 +0.002		1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANUD	Dm6	1	+0.008 +0.002		1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANUU	Dm6	1	+0.008 +0.002		1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANUX	Dm6	1	+0.008 +0.002		1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANUL	Dm6	1	+0.008 +0.002		1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANQD	Dm6	1	+0.008 +0.002		1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANFD	Dp6	1		+0.012 +0.006	1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANFU	Dp6	1		+0.012 +0.006	1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANFX	Dp6	1		+0.012 +0.006	1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANFL	Dp6	1		+0.012 +0.006	1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANOD	Dp6	1		+0.012 +0.006	1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANXD	Dp6	1		+0.012 +0.006	1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANXU	Dp6	1		+0.012 +0.006	1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANXX	Dp6	1		+0.012 +0.006	1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANXL	Dp6	1		+0.012 +0.006	1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANLD	Dp6	1		+0.012 +0.006	1.50~3.00	2~3	1.5~6.0	0.1	0	—
JT-RANSD	Dm6	2	+0.008 +0.002		2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANSU	Dm6	2	+0.008 +0.002		2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANSX	Dm6	2	+0.008 +0.002		2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANSL	Dm6	2	+0.008 +0.002		2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANDD	Dm6	2	+0.008 +0.002		2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANUD	Dm6	2	+0.008 +0.002		2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANUU	Dm6	2	+0.008 +0.002		2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANUX	Dm6	2	+0.008 +0.002		2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANUL	Dm6	2	+0.008 +0.002		2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANQD	Dm6	2	+0.008 +0.002		2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANFD	Dp6	2		+0.012 +0.006	2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANFU	Dp6	2		+0.012 +0.006	2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANFX	Dp6	2		+0.012 +0.006	2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANFL	Dp6	2		+0.012 +0.006	2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANOD	Dp6	2		+0.012 +0.006	2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANXD	Dp6	2		+0.012 +0.006	2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANXU	Dp6	2		+0.012 +0.006	2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANXX	Dp6	2		+0.012 +0.006	2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANXL	Dp6	2		+0.012 +0.006	2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANLD	Dp6	2		+0.012 +0.006	2.50~6.00	2~8	1.5~15.0	0.5	0	1.2
JT-RANSD	Dm6	3	+0.008 +0.002		3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANSU	Dm6	3	+0.008 +0.002		3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANSX	Dm6	3	+0.008 +0.002		3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANSL	Dm6	3	+0.008 +0.002		3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANDD	Dm6	3	+0.008 +0.002		3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANUD	Dm6	3	+0.008 +0.002		3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANUU	Dm6	3	+0.008 +0.002		3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANUX	Dm6	3	+0.008 +0.002		3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANUL	Dm6	3	+0.008 +0.002		3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANQD	Dm6	3	+0.008 +0.002		3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANFD	Dp6	3		+0.012 +0.006	3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANFU	Dp6	3		+0.012 +0.006	3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANFX	Dp6	3		+0.012 +0.006	3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANFL	Dp6	3		+0.012 +0.006	3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANOD	Dp6	3		+0.012 +0.006	3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANXD	Dp6	3		+0.012 +0.006	3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANXU	Dp6	3		+0.012 +0.006	3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANXX	Dp6	3		+0.012 +0.006	3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANXL	Dp6	3		+0.012 +0.006	3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANLD	Dp6	3		+0.012 +0.006	3.50~8.00	3~10	1.5~15.0	0.5	1	1.5
JT-RANSD	Dm6	4	+0.012 +0.004		4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANSU	Dm6	4	+0.012 +0.004		4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANSX	Dm6	4	+0.012 +0.004		4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANSL	Dm6	4	+0.012 +0.004		4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANDD	Dm6	4	+0.012 +0.004		4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANUD	Dm6	4	+0.012 +0.004		4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANUU	Dm6	4	+0.012 +0.004		4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANUX	Dm6	4	+0.012 +0.004		4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANUL	Dm6	4	+0.012 +0.004		4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANQD	Dm6	4	+0.012 +0.004		4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANFD	Dp6	4		+0.020 +0.012	4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANFU	Dp6	4		+0.020 +0.012	4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANFX	Dp6	4		+0.020 +0.012	4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANFL	Dp6	4		+0.020 +0.012	4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANOD	Dp6	4		+0.020 +0.012	4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANXD	Dp6	4		+0.020 +0.012	4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANXU	Dp6	4		+0.020 +0.012	4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANXX	Dp6	4		+0.020 +0.012	4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANXL	Dp6	4		+0.020 +0.012	4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANLD	Dp6	4		+0.020 +0.012	4.50~8.00	4~15	1.5~15.0	1	1	1.8
JT-RANSD	Dm6	5	+0.012 +0.004		5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANSU	Dm6	5	+0.012 +0.004		5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANSX	Dm6	5	+0.012 +0.004		5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANSL	Dm6	5	+0.012 +0.004		5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANDD	Dm6	5	+0.012 +0.004		5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANUD	Dm6	5	+0.012 +0.004		5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANUU	Dm6	5	+0.012 +0.004		5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANUX	Dm6	5	+0.012 +0.004		5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANUL	Dm6	5	+0.012 +0.004		5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANQD	Dm6	5	+0.012 +0.004		5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANFD	Dp6	5		+0.020 +0.012	5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANFU	Dp6	5		+0.020 +0.012	5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANFX	Dp6	5		+0.020 +0.012	5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANFL	Dp6	5		+0.020 +0.012	5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANOD	Dp6	5		+0.020 +0.012	5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANXD	Dp6	5		+0.020 +0.012	5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANXU	Dp6	5		+0.020 +0.012	5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANXX	Dp6	5		+0.020 +0.012	5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANXL	Dp6	5		+0.020 +0.012	5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANLD	Dp6	5		+0.020 +0.012	5.50~10.00	5~15	1.5~15.0	1	1	2.2
JT-RANSD	Dm6	6	+0.012 +0.004		6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANSU	Dm6	6	+0.012 +0.004		6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANSX	Dm6	6	+0.012 +0.004		6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANSL	Dm6	6	+0.012 +0.004		6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANDD	Dm6	6	+0.012 +0.004		6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANUD	Dm6	6	+0.012 +0.004		6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANUU	Dm6	6	+0.012 +0.004		6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANUX	Dm6	6	+0.012 +0.004		6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANUL	Dm6	6	+0.012 +0.004		6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANQD	Dm6	6	+0.012 +0.004		6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANFD	Dp6	6		+0.020 +0.012	6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANFU	Dp6	6		+0.020 +0.012	6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANFX	Dp6	6		+0.020 +0.012	6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANFL	Dp6	6		+0.020 +0.012	6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANOD	Dp6	6		+0.020 +0.012	6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANXD	Dp6	6		+0.020 +0.012	6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANXU	Dp6	6		+0.020 +0.012	6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANXX	Dp6	6		+0.020 +0.012	6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANXL	Dp6	6		+0.020 +0.012	6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANLD	Dp6	6		+0.020 +0.012	6.50~12.00	5~15	1.5~30.0	1	1	3
JT-RANSD	Dm6	8	+0.015 +0.006		8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANSU	Dm6	8	+0.015 +0.006		8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANSX	Dm6	8	+0.015 +0.006		8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANSL	Dm6	8	+0.015 +0.006		8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANDD	Dm6	8	+0.015 +0.006		8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANUD	Dm6	8	+0.015 +0.006		8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANUU	Dm6	8	+0.015 +0.006		8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANUX	Dm6	8	+0.015 +0.006		8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANUL	Dm6	8	+0.015 +0.006		8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANQD	Dm6	8	+0.015 +0.006		8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANFD	Dp6	8		+0.024 +0.015	8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANFU	Dp6	8		+0.024 +0.015	8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANFX	Dp6	8		+0.024 +0.015	8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANFL	Dp6	8		+0.024 +0.015	8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANOD	Dp6	8		+0.024 +0.015	8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANXD	Dp6	8		+0.024 +0.015	8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANXU	Dp6	8		+0.024 +0.015	8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANXX	Dp6	8		+0.024 +0.015	8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANXL	Dp6	8		+0.024 +0.015	8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANLD	Dp6	8		+0.024 +0.015	8.50~15.00	5~18	1.5~30.0	1.5	1	3.5
JT-RANSD	Dm6	10	+0.015 +0.006		11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANSU	Dm6	10	+0.015 +0.006		11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANSX	Dm6	10	+0.015 +0.006		11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANSL	Dm6	10	+0.015 +0.006		11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANDD	Dm6	10	+0.015 +0.006		11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANUD	Dm6	10	+0.015 +0.006		11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANUU	Dm6	10	+0.015 +0.006		11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANUX	Dm6	10	+0.015 +0.006		11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANUL	Dm6	10	+0.015 +0.006		11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANQD	Dm6	10	+0.015 +0.006		11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANFD	Dp6	10		+0.024 +0.015	11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANFU	Dp6	10		+0.024 +0.015	11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANFX	Dp6	10		+0.024 +0.015	11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANFL	Dp6	10		+0.024 +0.015	11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANOD	Dp6	10		+0.024 +0.015	11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANXD	Dp6	10		+0.024 +0.015	11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANXU	Dp6	10		+0.024 +0.015	11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANXX	Dp6	10		+0.024 +0.015	11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANXL	Dp6	10		+0.024 +0.015	11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANLD	Dp6	10		+0.024 +0.015	11.00~17.00	5~22	3.0~30.0	2	1	4
JT-RANSD	Dm6	12	+0.018 +0.007		13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANSU	Dm6	12	+0.018 +0.007		13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANSX	Dm6	12	+0.018 +0.007		13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANSL	Dm6	12	+0.018 +0.007		13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANDD	Dm6	12	+0.018 +0.007		13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANUD	Dm6	12	+0.018 +0.007		13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANUU	Dm6	12	+0.018 +0.007		13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANUX	Dm6	12	+0.018 +0.007		13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANUL	Dm6	12	+0.018 +0.007		13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANQD	Dm6	12	+0.018 +0.007		13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANFD	Dp6	12		+0.029 +0.018	13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANFU	Dp6	12		+0.029 +0.018	13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANFX	Dp6	12		+0.029 +0.018	13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANFL	Dp6	12		+0.029 +0.018	13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANOD	Dp6	12		+0.029 +0.018	13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANXD	Dp6	12		+0.029 +0.018	13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANXU	Dp6	12		+0.029 +0.018	13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANXX	Dp6	12		+0.029 +0.018	13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANXL	Dp6	12		+0.029 +0.018	13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANLD	Dp6	12		+0.029 +0.018	13.00~20.00	6~26	3.0~30.0	2	1	5
JT-RANSD	Dm6	13	+0.018 +0.007		14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANSU	Dm6	13	+0.018 +0.007		14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANSX	Dm6	13	+0.018 +0.007		14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANSL	Dm6	13	+0.018 +0.007		14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANDD	Dm6	13	+0.018 +0.007		14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANUD	Dm6	13	+0.018 +0.007		14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANUU	Dm6	13	+0.018 +0.007		14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANUX	Dm6	13	+0.018 +0.007		14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANUL	Dm6	13	+0.018 +0.007		14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANQD	Dm6	13	+0.018 +0.007		14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANFD	Dp6	13		+0.029 +0.018	14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANFU	Dp6	13		+0.029 +0.018	14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANFX	Dp6	13		+0.029 +0.018	14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANFL	Dp6	13		+0.029 +0.018	14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANOD	Dp6	13		+0.029 +0.018	14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANXD	Dp6	13		+0.029 +0.018	14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANXU	Dp6	13		+0.029 +0.018	14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANXX	Dp6	13		+0.029 +0.018	14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANXL	Dp6	13		+0.029 +0.018	14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANLD	Dp6	13		+0.029 +0.018	14.00~20.00	7~28	5.0~30.0	2	2	5.5
JT-RANSD	Dm6	16	+0.018 +0.007		17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANSU	Dm6	16	+0.018 +0.007		17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANSX	Dm6	16	+0.018 +0.007		17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANSL	Dm6	16	+0.018 +0.007		17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANDD	Dm6	16	+0.018 +0.007		17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANUD	Dm6	16	+0.018 +0.007		17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANUU	Dm6	16	+0.018 +0.007		17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANUX	Dm6	16	+0.018 +0.007		17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANUL	Dm6	16	+0.018 +0.007		17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANQD	Dm6	16	+0.018 +0.007		17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANFD	Dp6	16		+0.029 +0.018	17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANFU	Dp6	16		+0.029 +0.018	17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANFX	Dp6	16		+0.029 +0.018	17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANFL	Dp6	16		+0.029 +0.018	17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANOD	Dp6	16		+0.029 +0.018	17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANXD	Dp6	16		+0.029 +0.018	17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANXU	Dp6	16		+0.029 +0.018	17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANXX	Dp6	16		+0.029 +0.018	17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANXL	Dp6	16		+0.029 +0.018	17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANLD	Dp6	16		+0.029 +0.018	17.00~27.00	8~35	5.0~30.0	3	2	7
JT-RANSD	Dm6	20	+0.021 +0.008		22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANSU	Dm6	20	+0.021 +0.008		22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANSX	Dm6	20	+0.021 +0.008		22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANSL	Dm6	20	+0.021 +0.008		22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANDD	Dm6	20	+0.021 +0.008		22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANUD	Dm6	20	+0.021 +0.008		22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANUU	Dm6	20	+0.021 +0.008		22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANUX	Dm6	20	+0.021 +0.008		22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANUL	Dm6	20	+0.021 +0.008		22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANQD	Dm6	20	+0.021 +0.008		22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANFD	Dp6	20		+0.035 +0.022	22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANFU	Dp6	20		+0.035 +0.022	22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANFX	Dp6	20		+0.035 +0.022	22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANFL	Dp6	20		+0.035 +0.022	22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANOD	Dp6	20		+0.035 +0.022	22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANXD	Dp6	20		+0.035 +0.022	22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANXU	Dp6	20		+0.035 +0.022	22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANXX	Dp6	20		+0.035 +0.022	22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANXL	Dp6	20		+0.035 +0.022	22.00~30.00	10~42	5.0~30.0	3	2	9
JT-RANLD	Dp6	20		+0.035 +0.022	22.00~30.00	10~42	5.0~30.0	3	2	9

选型参数

圆型		多棱型		材质	硬度	表面处理
Dm6	Dp6	Dm6	Dp6	材质	硬度	表面处理
JT-RANSD	JT-RANFD	JT-RANUD	JT-RANXD	SKS3	淬火硬度58~61HRC	—
JT-RANSU	JT-RANFU	JT-RANUU	JT-RANXU	SKS3	淬火硬度58~61HRC,镀层硬度850HV~	镀硬铬+抛光 , 镀层厚度3~5μ m
JT-RANSX	JT-RANFX	JT-RANUX	JT-RANXX	SUS304	—	—
JT-RANSL	JT-RANFL	JT-RANUL	JT-RANXL	SUS304	镀层硬度850HV~	镀硬铬 , 镀层厚度5~8μm
JT-RANDD	JT-RANOD	—	—	SUS440C	淬火硬度48~53HRC	—
—	—	JT-RANQD	JT-RANLD	SUS440C	淬火硬度48~53HRC	抛光

抛光：//// 表示抛光加工部位。
SUS440C材质的D部加工有识别槽。
SUS304可能经研磨或无中心孔。
由于带有中心孔，因此P尺寸较小时，几乎看不见球面部。
工艺孔加工条件：D·L·B≥4且P≥6。(工艺孔详细尺寸见产品简介)
可选加工见上表。

可选加工参数

暂未上传文档资料

定位销 大头球面型 标准型

定位销大头球面型标准型
